Wireless Access Points · Wi-Fi 6

RUCKUS H350 Indoor Access Point

Reference H350

Entry-Level Wall-Mounted Wi-Fi 6 2x2:2 Indoor Access Point with 1.8 Gbps max rate, Switch and Embedded IoT

Wi-Fi 6Wi-Fi Generation
1774 Mb/sCombined Max PHY Rate
512Concurrent Users

RUCKUS H350 Indoor Access Point Features

In hotels, apartment buildings, and other multi-dwelling structures, wireless connectivity can carry a hefty price tag. You need to connect a wide range of wired devices - IPTV set-top boxes, IP phones, networked minibars - IoT devices like smart locks and sensors - while delivering a great wireless experience for guests.

The RUCKUS H350 wall-mounted access point, IoT gateway, and Ethernet switch make it easy to support in-room connectivity requirements. It starts with RUCKUS patented Wi-Fi optimization intelligence to deliver the industry's highest-performing wireless connectivity. Combine that with two-ports of Gigabit Ethernet to connect in-room wired devices, without extra cabling and add supports for Zigbee® or Bluetooth® Low Energy. Put it all in a sleek, low-profile design that can be discretely installed over a standard electrical outlet.

The RUCKUS® H350 delivers consistent, reliable Wi-Fi 6 (802.11ax) wireless networking without breaking the bank. The AP features the patented RUCKUS technologies for performance optimization and interference mitigation found in our premier access points, delivering superior user experiences. But it provides them in an entry-level product built for smaller venues with limited device diversity.

Specifications

RUCKUS H350 Indoor Access Point — Specifications
Specification	Value
Product classification
Regional Availability	Asia \| Australia/New Zealand \| EMEA \| Latin America \| North America
Product Type	Indoor access point
Product Brand	RUCKUS®
General Specifications
Antenna Patterns, per band	16
Antenna Gain	Up to 1 dBi
BeamFlex	Yes
ChannelFly	Yes
Concurrent Users	512
Controller Support	RUCKUS Cloud™ \| RUCKUS SmartZone \| RUCKUS Unleashed™ \| RUCKUS ZoneDirector
Ethernet Ports	3 x 1 GbE
IoT Support	IoT Onboard
Number of Radios	Dual-Radio
PD-MRC	Yes
PHY Rate at 2.4 GHz, maximum	574 Mb/s
PHY Rate at 5 GHz, maximum	1200 Mb/s
Combined Max PHY Rate	1774 Mb/s
Radio Chains and Streams	2x2:2
Rx Sensitivity at 2.4 GHz	-100 dBm
Rx Sensitivity at 5 GHz	-100 dBm
SmartMesh	Yes
USB	USB 2.0
Venue Type	Education \| Hospitality
Venue Sub-Type	Guest Rooms \| Residence Hall
Wi-Fi Bands Supported	2.4 GHz \| 5 GHz
Wi-Fi Generation	Wi-Fi 6
Wi-Fi Interface Standard	IEEE 802.11a/b/g/n/ac/ax
Environmental Specifications
Operating Temperature	0 °C to +40 °C (+32 °F to +104 °F)
