AT-2401-DP Antenna
Reference AT-2401-DP
5GHz dual polarized high gain 24dBi directional antenna
- 24.5 dBi/23.5 dBiAntenna Gain
- IP-67IP Rating
- 5 GHzWi-Fi Band
Specifications
| Specification | Value |
|---|---|
| Product classification | |
| Regional Availability | Asia | Australia/New Zealand | EMEA | Latin America | North America |
| Product Type | Antenna |
| Product Brand | RUCKUS® |
| General Specifications | |
| Application | Long range backhaul /PtP/PtMP Non-Root |
| Antenna Gain | 24.5 dBi/23.5 dBi |
| Polarization | Vertical & Horizontal |
| Connector Location | Two N-type, two 1 m RF cables included |
| IP Rating | IP-67 |
| Mounting | Wall/Pole Mount, mounting kit included |
| Wi-Fi Band | 5 GHz |
| Bandwidth H/V @ 3 dB | 7-9/7-9 degrees |
| Dimensions | |
| System Dimensions | 370 mm × 370 mm × 40 mm |
| Environmental Specifications | |
| Operating Temperature | -40 °C to +65 °C (-40 °F to +149 °F) |
| Packaging and Weights | |
| Weight, net | 1800 g | 3.968 lb |
